Kegco 20" Wide Single Tap Black Carbonated Water Kegerator

• Single tap draft dispense system comes with everything you need to dispense carbonated water from a keg
• Stylish black cabinet with reversible black door, removable drip tray, chrome guardrail, and textured serving counter-top
• Two included removable racks allow you to easily convert the sparkling water kegerator into a regular all-refrigerator when not dispensing kegs
• Knockout for CO2 maximizes internal space for kegs by allowing you to mount the CO2 tank externally
• Energy efficient design will leave a minimal impact on the environment and your electric bill

  Dimensions: 33" H x 20" W x 25.5" D

Specially designed for convenient residential use and fully equipped with a single tap keg dispense system, Kegco's CWK199B-1 Carbonated Water Kegerator is the easiest way to enjoy refreshing sparkling water any time you want. This energy efficient kegerator has a wide 32-75 degrees Fahrenheit adjustable temperature range to dispense ice cold water, and includes two adjustable wire shelves that allow you to convert the kegerator into a regular all-refrigerator when you aren't dispensing kegs.

Ideal for use in the home, the Kegco CWK199B-1 boasts a sleek black cabinet with matching door that fits in with any decor. It's packed with other convenient features like a dishwasher-safe drip tray, chrome guard rail, textured serving top, and 2-1/2" locking casters that make it easy to move this kegerator into any room of your home. The spacious 4.9 cubic foot interior can hold one full size, pony, or quarter slim keg, or up to two 5 gallon D system, ball lock, or pin lock kegs. A steel interior floor mat makes it easy to load your kegs in and out, and ensures long-lasting durability.

The CWK199B-1 comes complete with a single tap dispense system with everything you need to begin dispensing carbonated water from a keg. The kit includes a single faucet polished stainless steel draft tower, a commercial grade dual gauge regulator, an empty 5 lb. aluminum CO2 tank, and a complete set of ball lock keg couplers. This kit can be fully customized to best fit the type of keg you will be using.

• Includes a brand new 5 lb. Aluminum CO₂ Tank
  This tank is produced from high strength aluminum alloy 6061-T6, a highly corrosion-resistant material. The service pressure is up to 1800 PSI/124 BAR with a test pressure of 3000 PSI/207 BAR. These cylinders are stamped with the required U.S. Department of Transportation and Transport Canada Markings. The 320 Valves are CGA approved, and have a male thread for Co2 Regulators. An average fill is good for 5-6 kegs depending upon your fill.
• Includes Commercial Grade Double Gauge CO₂ Regulator
  This regulator works with any CO₂ tank with a CGA-320 valve. The top gauge measures PSI, indicating how much CO₂ pressure is inside of the keg. The side gauge measures the remaining volume of CO₂ in the tank, so you'll know when it's about time to get the tank filled. This regulator features a T-style adjustment valve that can be adjusted by hand, eliminating the need for a screwdriver.
• Includes 5 feet of 5/16 Inch I.D. Blue Air Line Assembly with 2 Worm Drive Clamps
  This 5 foot length of 5/16" I.D. Blue Air/CO₂ Tubing is made of Thermoplastic Vinyl Hose (Super Vinyl). It will not rot, swell, or dry out, and is unaffected by normal cleaning compounds. This air line assembly comes with two durable stainless steel worm drive clamps that can be easily installed or removed with a flat head screwdriver.
• Includes Ball Lock Home Brew Keg Tap Complete Set
  This complete ball lock home brew keg tap set includes both a gas in and beer out coupler for easy tapping of ball lock Cornelius Pepsi kegs. The gas in has a 1/4" nut and 5/16" hose barb already attached for easy connection to the air line. The beer out connector has a 3/16" hose barb that connects to the 3/16" beer line.
• Includes a Kegco Exclusive 14" Tall, 3" Diameter Polished Stainless Steel Draft Tower
  This NSF-approved tower is a 3" diameter single faucet metal draft tower made of polished stainless steel and includes 5 feet of 3/16" I.D. clear beer tubing. The faucet, shank, and fittings are all made of 304 grade stainless steel for the ultimate in sanitation. The tower is mounted using the gasket and four screws that are included. This Kegco Exclusive tower measures 14" tall, giving you an extra 2" of space over standard draft beer towers to allow you to easily fill tall growlers and pint glasses.
• All dispensing accessories are UL recognized components
• Black cabinet with reversible black door
• Includes 2 full-width wire shelves and a hole plug that allow you to convert the kegerator into a compact refrigerator
• Holds 1/2 barrel kegs, full size kegs (15.5 gallons), 1/4 barrels kegs, and pony kegs (7.75 gallons)
• Maximum Ambient Temperature: 100 degrees Fahrenheit
• Minimum Ambient Temperature: The lowest temperature you want to store your kegs at. The unit does not have a heater, so if the ambient temperature is lower than the set temperature, the internal temperature will match the external temperature.
• Removable drip tray with grill to collect spills
• Chrome guard rail to prevent your mugs and glasses from sliding off
• Steel interior floor mat for long lasting durability and easy glide of beer keg
• Textured serving counter top
• 25% more energy efficient design saves you money each month
• UL Listed

Brand	Full Size	Pony Size	Quarter slim	5 Gallon D System	5 Gallon Ball Lock	5 Gallon Pin Lock	5 Gallon Strap Handle
Kegco K199	1	1	1	2	2	2	2
Kegco K209	1	1	1	2	3	3	3
Kegco K309	1	1	1	2	3	3	3
Kegco VSK-15	0	0	0	1	1	1	1
Kegco SLK-15	0	0	0	1	1	1	1
Kegco Z163	1	1	1	2	3	2	3
Kegco HK38	1	1	2	3	3	3	3
Kegco XCK-1	1	1	2	4	4	4	4
Summit SBC677	1	1	1	2	3	2	3
Summit SBC635	1	1	1	2	3	3	3
Haier Kegerator	1	1	2*	2	3	3	3
Danby Kegerator	1	1	1	2	3	2	3
All Marvel Kegerators	1	1	1	2	3	3	3
Perlick HP15T	0	0	0	1	1	1	1
Perlick HP24T	0	1	0	2	2	1	2
Perlick HC24T	0	1	0	2	2	1	2
UBC Kegmaster	1	1	2	4**	3	4**	4**
Beverage Air BM23	1	1	2	3	4	4	4
Everest EBD1	1	1	1	2	3	3	3

Brand	Full Size	Pony Size	Quarter slim
Kegco K199	1	1	1
Kegco K209	1	1	1
Kegco K309	1	1	1
Kegco VSK-15	0	0	0
Kegco SLK-15	0	0	0
Kegco Z163	1	1	1
Kegco HK38	1	1	2
Kegco XCK-1	1	1	2
Summit SBC677	1	1	1
Summit SBC635	1	1	1
Haier Kegerator	1	1	2*
Danby Kegerator	1	1	1
All Marvel Kegerators	1	1	1
Perlick HP15T	0	0	0
Perlick HP24T	0	1	0
Perlick HC24T	0	1	0
UBC Kegmaster	1	1	2
Beverage Air BM23	1	1	2
Everest EBD1	1	1	1

Brand	5 Gallon D System	5 Gallon Ball Lock	5 Gallon Pin Lock	5 Gallon Strap Handle
Kegco K199	2	2	2	2
Kegco K209	2	3	3	3
Kegco K309	2	3	3	3
Kegco VSK-15	1	1	1	1
Kegco SLK-15	1	1	1	1
Kegco Z163	2	3	2	3
Kegco HK38	3	3	3	3
Kegco XCK-1	4	4	4	4
Summit SBC677	2	3	2	3
Summit SBC635	2	3	3	3
Haier Kegerator	2	3	3	3
Danby Kegerator	2	3	2	3
All Marvel Kegerators	2	3	3	3
Perlick HP15T	1	1	1	1
Perlick HP24T	2	2	1	2
Perlick HC24T	2	2	1	2
UBC Kegmaster	4**	3	4**	4**
Beverage Air BM23	3	4	4	4
Everest EBD1	2	3	3	3

* - Using Wood riser for front keg

** - With external CO2 tank (3 with internal CO2 tank)

Labor - 12 Months

For one year from the date of purchase by the original owner, Kegco will, at its option, repair or replace any part of the unit, which proves to be defective in material or workmanship under normal use. During this period Kegco will provide all parts and labor necessary to correct such defects free of charge, so long as the unit has been installed and operated in accordance with the written instructions in this manual. Kegco will provide you with a reasonably similar replacement product that is either new or factory refurbished. In rental or commercial use, the warranty period is 90 days. All Kegco Appliances of 3.5 cubic feet capacity or less must be brought/sent to the appliance service shop for repair.

Parts - 60 Months

For the second through the fifth year from date of original purchase, Kegco Products will provide a replacement compressor free of charge due to a failure. You are responsible for the service labor and freight charges. In rental or commercial use, the limited compressor warranty is one year and nine months. Cost to move the appliance to the servicers’ shop and back to the user's home, as may be required, are the user's responsibility.

Additional Details

• Content losses of food or other, due to spoilage.
• Incidental or consequential damages.
• Parts and labor costs for the following will not be considered as warranty:
  • Door springs, and/or frames.
  • Inner door panels, door rails and/or door supports.
  • Light bulbs and/or plastic housing.
  • Plastic cabinet liners.
  • Punctured evaporator that voids the warranty on the complete sealed system.
  • Repairs performed by unauthorized servicers.
  • Shipping and handling costs associated with the replacement of the unit.
  • Service calls that do not involve defects in material or workmanship such as customer education, door reversal, or proper installation.
  • Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip charges, or mileage expense for service call to remote areas, including the State of Alaska.
  • Service calls that are related to external problems, such as abuse, misuse, inadequate electrical power, accidents, fire, floods, or acts of God.
  • Replacement of house fuses or resetting circuit breakers.
• Failure of the product if it is used for other than its intended purpose.
• This warranty does not apply outside the Continental USA.
