Kegco 24" Wide Single Tap All Stainless Steel Commercial Kegerator

• Ideal for small bars, pubs, restaurants, and wine or beer tasting rooms!
• Rugged steel construction with Stainless Steel top and built-in drip tray that collects spills
• Can hold two Quarter Slim kegs or up to four 5 Gallon Kegs with external CO₂ Tank
• Customize the dispense system for things like draft beer, soda or wine
• ETL and ETL Sanitation Listed; NSF Compliant

The Kegco XCK-1S Commercial Kegerator is equally suitable for use in a trendy bar or in your very own man cave. This keg beer cooler is durably built to withstand the abuse of retail environments like a restaurant or tasting room but small and portable enough to easily move it from your kitchen to your patio. It is ETL and ETL Sanitation Listed and NSF Compliant, ensuring that it has met the requirements of widely accepted product safety standards for draft beer dispensers. The XCK-1S is an excellent choice for any small business that wants to offer beer, wine or cold-brewed coffee on tap and is affordable enough to dispense like the pros at home!

1. Blower Hose for Air-Cooled Tower

   Keep the beer line cooled all the way up to the back of the faucet

2. Fan-Forced Cooling

   An interior fan provides rapid cool down and ensures consistent temperatures

3. Internal Thermometer

   Quickly and accurately monitor the internal temperature at a glance

4. Knockout for external CO₂ Tank or Drain Hose

   This knockout allows you to mount your CO₂ Tank outside the cabinet or direct the drip tray runoff to an external drain

5. Drip Tray Drain Receptacle

   Any spills from the faucet can be directed into this bottle for quick and easy cleaning

6. Steel Walls

   Behind these walls lies foamed in place polyurethane insulation to maintain a specific steady temperature

7. Rubber Floor Mat

   A rubber floor mat reduces the shock of heavy kegs on the stainless steel floor

4" locking casters make this beer dispenser easy to move, while the built-in drip tray and steel interior make it easy to clean. A 1/7 hp compressor provides cooling and cool air is fan-forced into the tower to ensure your beer is cold all the way up to the faucet. It comes with a Kegco Exclusive 14" tall air-cooled 3" diameter draft tower, so if your direct draw will be provided by your beer distributor, you're all set. Beverage Factory offers the ability to add a custom draft system with our top quality selection of regulators, couplers and fittings. See the available options below and feel free to contact our expert staff with any questions you may have.

• Keg Storage Capacities:
• One (1) Full Size / 1/2-Barrel (15.5 Gal.)
• One (1) Pony Size / 1/4-Barrel Short (7.75 Gal.)
• Two (2) 1/4-Barrel Slim (7.75 Gal.) or
• Four (4) 1/6-Barrel (5.23 Gal.)
• Maximum Ambient Temperature: 90 degrees Fahrenheit
• Minimum Ambient Temperature: The lowest temperature you want to store your wine at. The unit does not have a heater, so if the ambient temperature is lower than the set temperature, the internal temperature will match the external temperature.
• Continuous Cold Air Channeled Through Tower to Ensure Cold Product
• Heavy-Duty Stainless Steel Top
• Built-In Drip Tray with Drain
• Stainless Steel Interior Walls and Ceiling
• Rubber Floor Mat prevents damage to interior
• Magnetic Gasket Provides Positive Door Sealing
• Self-Closing Door with Lock
• Refrigeration System Utilizes Ozone Friendly R134a Refrigerant
• CFC-Free Foamed-in-Placed Polyurethane Insulation
• Knockout for Remote CO₂ or Nitrogen Tank
• Stainless Steel Finish
• ETL and ETL Sanitation Listed for Commercial Use

Keg Configurations:

Some configurations require external CO₂ Tank mount.

Brand	Full Size	Pony Size	Quarter slim	5 Gallon D System	5 Gallon Ball Lock	5 Gallon Pin Lock	5 Gallon Strap Handle
Kegco K199	1	1	1	2	2	2	2
Kegco K209	1	1	1	2	3	3	3
Kegco K309	1	1	1	2	3	3	3
Kegco VSK-15	0	0	0	1	1	1	1
Kegco SLK-15	0	0	0	1	1	1	1
Kegco Z163	1	1	1	2	3	2	3
Kegco HK38	1	1	2	3	3	3	3
Kegco XCK-1	1	1	2	4	4	4	4
Summit SBC677	1	1	1	2	3	2	3
Summit SBC635	1	1	1	2	3	3	3
Haier Kegerator	1	1	2*	2	3	3	3
Danby Kegerator	1	1	1	2	3	2	3
All Marvel Kegerators	1	1	1	2	3	3	3
Perlick HP15T	0	0	0	1	1	1	1
Perlick HP24T	0	1	0	2	2	1	2
Perlick HC24T	0	1	0	2	2	1	2
UBC Kegmaster	1	1	2	4**	3	4**	4**
Beverage Air BM23	1	1	2	3	4	4	4
Everest EBD1	1	1	1	2	3	3	3

Brand	Full Size	Pony Size	Quarter slim
Kegco K199	1	1	1
Kegco K209	1	1	1
Kegco K309	1	1	1
Kegco VSK-15	0	0	0
Kegco SLK-15	0	0	0
Kegco Z163	1	1	1
Kegco HK38	1	1	2
Kegco XCK-1	1	1	2
Summit SBC677	1	1	1
Summit SBC635	1	1	1
Haier Kegerator	1	1	2*
Danby Kegerator	1	1	1
All Marvel Kegerators	1	1	1
Perlick HP15T	0	0	0
Perlick HP24T	0	1	0
Perlick HC24T	0	1	0
UBC Kegmaster	1	1	2
Beverage Air BM23	1	1	2
Everest EBD1	1	1	1

Brand	5 Gallon D System	5 Gallon Ball Lock	5 Gallon Pin Lock	5 Gallon Strap Handle
Kegco K199	2	2	2	2
Kegco K209	2	3	3	3
Kegco K309	2	3	3	3
Kegco VSK-15	1	1	1	1
Kegco SLK-15	1	1	1	1
Kegco Z163	2	3	2	3
Kegco HK38	3	3	3	3
Kegco XCK-1	4	4	4	4
Summit SBC677	2	3	2	3
Summit SBC635	2	3	3	3
Haier Kegerator	2	3	3	3
Danby Kegerator	2	3	2	3
All Marvel Kegerators	2	3	3	3
Perlick HP15T	1	1	1	1
Perlick HP24T	2	2	1	2
Perlick HC24T	2	2	1	2
UBC Kegmaster	4**	3	4**	4**
Beverage Air BM23	3	4	4	4
Everest EBD1	2	3	3	3

* - Using Wood riser for front keg

** - With external CO2 tank (3 with internal CO2 tank)

Labor - 12 Months

For one year from the date of purchase by the original owner, Kegco will, at its option, repair or replace any part of the unit, which proves to be defective in material or workmanship under normal use. During this period Kegco will provide all parts and labor necessary to correct such defects free of charge, so long as the unit has been installed and operated in accordance with the written instructions in this manual. Kegco will provide you with a reasonably similar replacement product that is either new or factory refurbished. In rental or commercial use, the warranty period is 90 days. All Kegco Appliances of 3.5 cubic feet capacity or less must be brought/sent to the appliance service shop for repair.

Parts - 60 Months

For the second through the fifth year from date of original purchase, Kegco Products will provide a replacement compressor free of charge due to a failure. You are responsible for the service labor and freight charges. In rental or commercial use, the limited compressor warranty is one year and nine months. Cost to move the appliance to the servicers’ shop and back to the user's home, as may be required, are the user's responsibility.

Additional Details

• Content losses of food or other, due to spoilage.
• Incidental or consequential damages.
• Parts and labor costs for the following will not be considered as warranty:
  • Door springs, and/or frames.
  • Inner door panels, door rails and/or door supports.
  • Light bulbs and/or plastic housing.
  • Plastic cabinet liners.
  • Punctured evaporator that voids the warranty on the complete sealed system.
  • Repairs performed by unauthorized servicers.
  • Shipping and handling costs associated with the replacement of the unit.
  • Service calls that do not involve defects in material or workmanship such as customer education, door reversal, or proper installation.
  • Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip charges, or mileage expense for service call to remote areas, including the State of Alaska.
  • Service calls that are related to external problems, such as abuse, misuse, inadequate electrical power, accidents, fire, floods, or acts of God.
  • Replacement of house fuses or resetting circuit breakers.
• Failure of the product if it is used for other than its intended purpose.
• This warranty does not apply outside the Continental USA.
