Kegco 24" Wide Homebrew Single Tap Black Commercial Kegerator

• Industrial-strength cabinet can withstand punishment in restaurants, pubs, tasting rooms or your home!
• This beer dispenser has a pre-configured direct draw kit that includes everything you need to dispense two home brew ball lock kegs
• Fan-Forced Cooling provides rapid cool down and a blower hose directs cool air into the tower to keep the beer line cold all the way up to the faucet
• Built-in drip tray channels runoff into a drain receptacle inside the unit for quick and convenient clean up
• ETL and ETL Sanitation Listed and NSF Compliant for commercial use

The Kegco HBK1XB-1 Home Brew Kegerator is equally suitable for use in a trendy bar or in your very own man cave. This commercial grade keg beer cooler is durably built to withstand the abuse of retail environments like a restaurant or tasting room but small and portable enough to easily move it from place to place. It is ETL and ETL Sanitation Listed and NSF Compliant, ensuring that it has met the requirements of widely accepted product safety standards for draft beer dispensers. The HBK1XB-1 comes complete with all the components necessary to serve your own home brewed beer from a ball lock keg and features a Kegco Exclusive 14" tall polished stainless steel draft tower, a Commercial Grade Double Gauge CO₂ Regulator and an aluminum 5 lb CO₂ tank with a corrosion resistant glossy red coating - a $25 value at no additional charge!

1. Blower Hose for Air-Cooled Tower

   Keep the beer line cooled all the way up to the back of the faucet

2. Fan-Forced Cooling

   An interior fan provides rapid cool down and ensures consistent temperatures

3. Internal Thermometer

   Quickly and accurately monitor the internal temperature at a glance

4. Knockout for external CO₂ Tank or Drain Hose

   This knockout allows you to mount your CO₂ Tank outside the cabinet or direct the drip tray runoff to an external drain

5. Drip Tray Drain Receptacle

   Any spills from the faucet can be directed into this bottle for quick and easy cleaning

6. Steel Walls

   Behind these walls lies foamed in place polyurethane insulation to maintain a specific steady temperature

7. Rubber Floor Mat

   A rubber floor mat reduces the shock of heavy kegs on the stainless steel floor

4" locking casters make this beer dispenser easy to move, while the built-in drip tray and steel interior make it easy to clean. A 1/7 hp compressor provides cooling and cool air is fan-forced into the tower to ensure your beer is cold all the way up to the faucet. It comes with a Kegco Exclusive 14" tall air-cooled 3" diameter draft tower, so if your direct draw will be provided by your beer distributor, you're all set. Beverage Factory offers the ability to add a custom draft system with our top quality selection of regulators, couplers and fittings. See the available options below and feel free to contact our expert staff with any questions you may have.

• Includes a brand new 5 lb. Aluminum CO₂ Tank with Electric Red Epoxy Finish
  This tank is produced from high strength aluminum alloy 6061-T6, a highly corrosion-resistant material. It features an eye-catching glossy powder coated epoxy finish in Electric Red that acts as an extra layer of protection against corrosion and wear. The service pressure is up to 1800 PSI/124 BAR with a test pressure of 3000 PSI/207 BAR. These cylinders are stamped with the required U.S. Department of Transportation and Transport Canada Markings. The 320 Valves are CGA approved, and have a male thread for Co2 Regulators. An average fill is good for 5-6 kegs depending upon your fill.
• Includes Commercial Grade Double Gauge CO₂ Regulator
  This regulator works with any CO₂ tank with a CGA-320 valve. The top gauge measures PSI, indicating how much CO₂ pressure is inside of the keg. The side gauge measures the remaining volume of CO₂ in the tank, so you'll know when it's about time to get the tank filled. This regulator features a T-style adjustment valve that can be adjusted by hand, eliminating the need for a screwdriver.
• Includes 5 feet of 5/16 Inch I.D. Blue Air Line Assembly with 2 Worm Drive Clamps
  This 5 foot length of 5/16" I.D. Blue Air/CO₂ Tubing is made of Thermoplastic Vinyl Hose (Super Vinyl). It will not rot, swell, or dry out, and is unaffected by normal cleaning compounds. This air line assembly comes with two durable stainless steel worm drive clamps that can be easily installed or removed with a flat head screwdriver.
• Includes Ball Lock Home Brew Keg Tap Complete Set
  This complete ball lock home brew keg tap set includes both a gas in and beer out coupler for easy tapping of ball lock Cornelius Pepsi kegs. The gas in has a 1/4" nut and 5/16" hose barb already attached for easy connection to the air line. The beer out connector has a 3/16" hose barb that connects to the 3/16" beer line.
• Includes a Kegco Exclusive 14" Tall, 3" Diameter Polished Stainless Steel Draft Tower
  This NSF-approved tower is a 3" diameter single faucet metal draft tower made of polished stainless steel. It comes complete with a stainless steel faucet and 5 feet of 3/16 inch I.D. clear beer tubing. The tower is mounted using the gasket and four screws that are included. This Kegco Exclusive tower measures 14" tall, giving you an extra 2" of space over standard draft beer towers.
• Continuous Cold Air Channeled Through Tower to Ensure Cold Product
• Heavy-Duty Stainless Steel Top
• Built-In Drip Tray with Drain
• Stainless Steel Interior Walls and Ceiling
• Shock Reducing Rubber Floor Mat
• Magnetic Gasket Provides Positive Door Sealing
• Self-Closing Door with Lock
• Refrigeration System Utilizes Ozone Friendly R134a Refrigerant
• CFC-Free Foamed-in-Placed Polyurethane Insulation
• Knockout for Remote CO₂ or Nitrogen Tank
• Black Finish
• ETL and ETL Sanitation Listed for Commercial Use
• Maximum Ambient Temperature: 90 degrees Fahrenheit
• Minimum Ambient Temperature: The lowest temperature you want to store your kegs at. The unit does not have a heater, so if the ambient temperature is lower than the set temperature, the internal temperature will match the external temperature.

Brand	Full Size	Pony Size	Quarter slim	5 Gallon D System	5 Gallon Ball Lock	5 Gallon Pin Lock	5 Gallon Strap Handle
Kegco K199	1	1	1	2	2	2	2
Kegco K209	1	1	1	2	3	3	3
Kegco K309	1	1	1	2	3	3	3
Kegco VSK-15	0	0	0	1	1	1	1
Kegco SLK-15	0	0	0	1	1	1	1
Kegco Z163	1	1	1	2	3	2	3
Kegco HK38	1	1	2	3	3	3	3
Kegco XCK-1	1	1	2	4	4	4	4
Summit SBC677	1	1	1	2	3	2	3
Summit SBC635	1	1	1	2	3	3	3
Haier Kegerator	1	1	2*	2	3	3	3
Danby Kegerator	1	1	1	2	3	2	3
All Marvel Kegerators	1	1	1	2	3	3	3
Perlick HP15T	0	0	0	1	1	1	1
Perlick HP24T	0	1	0	2	2	1	2
Perlick HC24T	0	1	0	2	2	1	2
UBC Kegmaster	1	1	2	4**	3	4**	4**
Beverage Air BM23	1	1	2	3	4	4	4
Everest EBD1	1	1	1	2	3	3	3

Brand	Full Size	Pony Size	Quarter slim
Kegco K199	1	1	1
Kegco K209	1	1	1
Kegco K309	1	1	1
Kegco VSK-15	0	0	0
Kegco SLK-15	0	0	0
Kegco Z163	1	1	1
Kegco HK38	1	1	2
Kegco XCK-1	1	1	2
Summit SBC677	1	1	1
Summit SBC635	1	1	1
Haier Kegerator	1	1	2*
Danby Kegerator	1	1	1
All Marvel Kegerators	1	1	1
Perlick HP15T	0	0	0
Perlick HP24T	0	1	0
Perlick HC24T	0	1	0
UBC Kegmaster	1	1	2
Beverage Air BM23	1	1	2
Everest EBD1	1	1	1

Brand	5 Gallon D System	5 Gallon Ball Lock	5 Gallon Pin Lock	5 Gallon Strap Handle
Kegco K199	2	2	2	2
Kegco K209	2	3	3	3
Kegco K309	2	3	3	3
Kegco VSK-15	1	1	1	1
Kegco SLK-15	1	1	1	1
Kegco Z163	2	3	2	3
Kegco HK38	3	3	3	3
Kegco XCK-1	4	4	4	4
Summit SBC677	2	3	2	3
Summit SBC635	2	3	3	3
Haier Kegerator	2	3	3	3
Danby Kegerator	2	3	2	3
All Marvel Kegerators	2	3	3	3
Perlick HP15T	1	1	1	1
Perlick HP24T	2	2	1	2
Perlick HC24T	2	2	1	2
UBC Kegmaster	4**	3	4**	4**
Beverage Air BM23	3	4	4	4
Everest EBD1	2	3	3	3

* - Using Wood riser for front keg

** - With external CO2 tank (3 with internal CO2 tank)

Labor - 12 Months

For one year from the date of purchase by the original owner, Kegco will, at its option, repair or replace any part of the unit, which proves to be defective in material or workmanship under normal use. During this period Kegco will provide all parts and labor necessary to correct such defects free of charge, so long as the unit has been installed and operated in accordance with the written instructions in this manual. Kegco will provide you with a reasonably similar replacement product that is either new or factory refurbished. In rental or commercial use, the warranty period is 90 days. All Kegco Appliances of 3.5 cubic feet capacity or less must be brought/sent to the appliance service shop for repair.

Parts - 60 Months

For the second through the fifth year from date of original purchase, Kegco Products will provide a replacement compressor free of charge due to a failure. You are responsible for the service labor and freight charges. In rental or commercial use, the limited compressor warranty is one year and nine months. Cost to move the appliance to the servicers’ shop and back to the user's home, as may be required, are the user's responsibility.

Additional Details

• Content losses of food or other, due to spoilage.
• Incidental or consequential damages.
• Parts and labor costs for the following will not be considered as warranty:
  • Door springs, and/or frames.
  • Inner door panels, door rails and/or door supports.
  • Light bulbs and/or plastic housing.
  • Plastic cabinet liners.
  • Punctured evaporator that voids the warranty on the complete sealed system.
  • Repairs performed by unauthorized servicers.
  • Shipping and handling costs associated with the replacement of the unit.
  • Service calls that do not involve defects in material or workmanship such as customer education, door reversal, or proper installation.
  • Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip charges, or mileage expense for service call to remote areas, including the State of Alaska.
  • Service calls that are related to external problems, such as abuse, misuse, inadequate electrical power, accidents, fire, floods, or acts of God.
  • Replacement of house fuses or resetting circuit breakers.
• Failure of the product if it is used for other than its intended purpose.
• This warranty does not apply outside the Continental USA.
