- Customizable panel-ready door frames to match the rest of your cabinetry
- Digital control panel allows you to precisely set the temperature between 41-61 F in the upper zone and 45-64 F in the lower zone
- Glide out shelves on ball bearing tracks extend 90% allowing easy access to the back row of your collection
- Utilizes the most energy efficient compressor on the market, with ultra-low vibration and quiet operation
- Designed for built-in use
Note: Unit comes with unfinished door and does not come with handle
Dimensions: 70" H x 22" W x 22.125" D
Panel-Ready Door Frames
Customizable overlay panels (not included) to match the rest of your cabinetry.
90% Shelf Extension
Easily access your back row collection without the need of removing any front row obstacles.
Temperature Display
Clear digital display with easy touch button controls.
3 Color LED Lighting System
Illuminate the interior with three different LED colors; White, Blue or Orange.
Zero-Clearance Hinge
No side clearance needed to open door.
Elegant Wood Shelving
Sturdy wood shelves hold your bottles without sagging, while still maximizing space for your growing collection.
- Customizable panel-ready overlay door frames to seamlessly match the rest of your cabinetry
- Elegant sturdy wood shelves hold your bottles without sagging, while still maximizing space for your growing collection
- 101 bottle capacity - 14 extendable rolling shelves that can hold 6 bottles each, with a bottom shelf that can stack 17 more bottles. The maximum capacity can be reached with many different bottle sizes and is only affected when adding larger Pinot and Champagne bottles.
- All black interior emulates the traditional wine cellar
- 3 different colored LED lighting beautifully illuminates the interior without the heat created by an incandescent bulb
- Roller-glide shelves extend effortlessly, minimizing agitation to the wine
- Two independently controlled temperature zones
- Upper Zone: The temperature setting can be adjusted between 41°F to 61°F
- Lower Zone: The temperature setting can be adjusted between 45°F to 64°F
Note: The lower zone must be set at least 4° and no more than 12° higher than upper zone. It is normal for there to be a 3-5° variance between the top and bottom of a zone.
- Maximum Ambient Temperature: 90°F
- Minimum Ambient Temperature: The lowest temperature you want to store your wine at. The unit does not have a heater, so if the ambient temperature is lower than the set temperature, the internal temperature will match the external temperature.
- Internal fans circulate air for even cooling and faster cooldown
- Dimensions: 70"H x 22"W x 22.125"D
- Weight:
- Please Note: This unit does not come with handles
Dimensions | |
---|---|
Height | 69.5" |
Width | 21.5" |
Depth | 22.25" |
Weight | |
---|---|
Unit Weight | 163 lbs. |
Shipping Weight | 217 lbs. |
Warranty | |
---|---|
Labor | 1 Year |
Parts | 1 Year |
Compressor (Parts Only) | 5 Years |
Key Features | |
---|---|
Built-in Capable | Yes |
Security Lock | No |
Multiple / Dual Zone | Yes |
Beverage Center | No |
Cabinet Color / Material | Black |
ADA Compliant | No |
Commercial Use | No |
Outdoor Use | No |
Energy Star Rated | No |
Capacity | |
---|---|
Wine Bottle Count | Up to 101 Bottles |
Controls | |
---|---|
Adjustable Thermostat | Yes |
Digital | Yes |
Cooling System | |
---|---|
Type | Compressor |
Defrost System | Auto |
Front Ventilation | Yes |
Shelving | |
---|---|
Type | Glide-Out |
Number of Shelves | 14 |
Material | Wood |
Removable | Yes |
Adjustable | No |
Glide-Out (Roller Assemblies) | Yes |
Bottles per Shelf | 6 Bottles |
Interior | |
---|---|
Color | Black |
Compartments (Distinct Zones) | 2 |
Lighting | LED |
Door | |
---|---|
Type | Glass |
Number of Doors | 1 |
Color / Material | Panel Ready Frame |
Door Handle | No Handle |
Field Reversible | Yes |
Accepts Custom Panel | Yes |
Tinted / UV Protective | Yes |
Self-Closing | No |
Electrical | |
---|---|
Electrical Requirements | 120 V / 60 Hz |
Running Amps | 1.8 A |
Labor - 12 Months
LIMITED ONE YEAR WARRANTYFor one year from the date of purchase by the original owner, Allavino will, at its option, repair or replace any part of theunit, which proves to be defective in material or workmanship under normal use. During this period Allavino will provide all parts and labor necessary to correct such defects free of charge, so long as the unit has been installed and operated in accordance with the written instructions in the user manual. In cases where a product cannot be repaired, Allavino will provide you with a reasonably similar replacement product that is either new or factory refurbished. In rental or commercial use, the warranty period is 90 days. All Allavino Appliances of 3.5 cubic feet capacity or less must be brought/sent to the appliance service shop for repair.
Parts - 60 Months
LIMITED SECOND THROUGH FIFTH YEAR WARRANTY:For the second through the fifth year from date of original purchase, Allavino Products will provide a replacement compressor free of charge due to a failure. You are responsible for the service labor and freight charges. In rental or commercial use, the limited compressor warranty is one year and nine months. Cost to move the appliance to the servicers' shop and back to the user's home, as may be required, are the user's responsibility.
Additional Details
WHAT IS NOT COVERED:- Content losses of food or other, due to spoilage.
- Incidental or consequential damages.
- Parts and labor costs for the following will not be considered as warranty:
- Door springs, and/or frames.
- Inner door panels, door rails and/or door supports.
- Light bulbs and/or plastic housing.
- Plastic cabinet liners.
- Punctured evaporator that voids the warranty on the complete sealed system.
- Repairs performed by unauthorized servicers.
- Shipping and handling costs associated with the replacement of the unit.
- Service calls that do not involve defects in material or workmanship such as customer education, door reversal, or proper installation.
- Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip charges, or mileage expense for service call to remote areas, including the State of Alaska.
- Service calls that are related to external problems, such as abuse, misuse, inadequate electrical power, accidents, fire, floods, or acts of God.
- Replacement of house fuses or resetting circuit breakers.
- Failure of the product if it is used for other than its intended purpose.
- This warranty does not apply outside the Continental USA.
This item ships via Standard Door to Door Freight Service.
Please note: Free Shipping does not include White Glove Service. If you require White Glove Delivery service where they unpack it, place it where you want it, and remove the packing materials, it will require additional charges. Please call us at 800.710.9939 if you would like to upgrade to White Glove Service.
Shipping rates apply for orders shipped to the contiguous 48 US states. For orders to Alaska, Hawaii, Puerto Rico, APO/FPO addresses and international locations, please call 800.710.9939 for current rates. Sorry, we cannot ship items to a P.O. box.
